88 Series CATV OUTDOOR TAPS

Taikan’s 88 series Outdoor Taps have been designed with the future of the CATV industry in mind. The 88 series 1 and 1.2 GHz bandwidth options support DOCSIS 3.1 (FDD), while our 1.8 GHz bandwidth option supports Full Duplex DOCSIS (FDX) systems to offer additional usage and Broadband services. All units come complete with a factory installed power passing bar for uninterrupted service when the faceplate is removed. Interchangeable faceplates with the 2, 4, and 8 port models allow for future network growth while minimizing costly equipment upgrades for providers. All taps are backed by Taikan’s one year limited warranty.



lightning square button.jpg

electrical & safety features

  • 5-1800 MHz Bandwidth (1, 1.2, and 1.8 GHz Bandwidth
    Options Available)

  • 12 Amp Current Capacity

  • Blocking Capacitors on the "F" ports for Extended
    Surge Resistance

  • ANSI/SCTE 01-2015 Fully Compliant F-Connectors

  • Power Passing Option: CB Continuous through Signal
    without Faceplate

  • Surge Withstand C62.41-2002 IEEE C6241 Category B3/6kV Combination Wave, 3000 Amp

  • Compliant with SCTE Guidelines

  • Printed Circuit Boards



Design square button.jpg

housing & Mechanical design

  • Aluminum Alloy Housing Used for Corrosion Resistance

  • Widebody Housing (2, 4, and 8 Ports)

  • Rubber Gasket & RFI Shielding at 120 dB

  • Epoxy Sealed & Nickel Plated Brass "F" Ports

  • Double Polyurethane Coating for Greater Weather Protection

  • Easily Interchangeable Faceplates

  • Aerial or Pedestal Installation




optional features

  • Reverse Window Option

  • Conditioning Ready Option



specifications
